Schneider
BMXFCC103 - Cord set - 40-way terminal - 2 x HE10 connector - for M340 I/O - 1 m
| Kode Produk | BMXFCC103 |
| Brand | Schneider |
| Kategori | Wiring Accessories |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
This preassembled cordset is part of the Modicon X80 modules. It is compatible with 32-channels I/O modules. It enables the connection between I/O of modules with 40-way connectors to Modicon Telefast ABE7 rapid wiring connection. It is equipped with one 40-way connector at one end and two HE 10 connectors at the other end, and is 1 meter long.
Spesifikasi
| Range of product | Modicon X80 |
|---|---|
| Accessory / separate part type | Preformed cordset |
| Accessory / separate part designation | Preformed cordset for Telefast Advantys ABE7 sub-bases |
| Accessory / separate part destination | For I/O module with 40-way connectors |
| Number of cables | 2 |
| Electrical connection | 1 connector 40 ways 2 connectors HE10 |
| Cable length | 1 m |
| Total number of wires | 40 |
|---|---|
| Wire section | 0.324 mm² |
| Net weight | 0.35 kg |
