Schneider
VW3A3203 - Extended I/O module - discrete 6I/2O - analog 2I
| Kode Produk | VW3A3203 |
| Brand | Schneider |
| Kategori | Drives & Starters |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
This I/O expansion module enables your drive to meet the needs of application that manage additional or specific sensors. It is simple to install and remove from Altivar drives thanks to its modular withdrawable design. It is compatible with Altivar Process ATV600, Altivar Process ATV900 and Altivar Machine ATV340. It is also compatible with Altivar Easy 610. It has one removable spring terminal block 1.5 mm² / AWG 16.
Spesifikasi
| Product or component type | Additional I/O module |
|---|---|
| Range compatibility | Altivar Process ATV600 Altivar Machine ATV340 Altivar Process ATV900 Altivar ATV610 |
| Input/output type | 2 analog input configurable voltage, current or probe 6 discrete input 2 discrete output |
| Analogue input number | 2 |
| Analogue input type | AI4, AI5 configurable current: 0...20 mA/4...20 mA, sampling time: 0…1 ms, resolution: 14 bits AI4, AI5 configurable voltage: - 10...10 V DC, 24 V max, impedance: 20 kOhm, sampling time: 0…1 ms, resolution: 14 bits AI4, AI5 configurable PTC, Pt 100, Pt 1000, sampling time: 0…1 ms, resolution: 14 bits |
| Discrete output number | 2 |
| Discrete output type | (DQ11, DQ12) assignable logic, sampling time: 1 ms |
| Discrete output logic | (DQ11, DQ12) negative (DQ11, DQ12) positive |
| Discrete input number | 6 |
| Discrete input type | (DI11...DI16) programmable, impedance: 250 Ohm, sampling time: 1 ms |
| Discrete input logic | Negative (DI11...DI16) Positive (DI11...DI16) |
| Discrete input current | 2.5 mA |
| Discrete output voltage | 24 V DC (voltage limits: <= 30 V) assignable logic |
|---|---|
| Maximum output current | 100 mA, assignable logic |
| Discrete input voltage | 24 V DC (voltage limits: <= 30 V) for programmable |
| Electrical connection | Removable spring terminal block, 1.5 mm² / 16 AWG |
| Protection type | Reverse polarity protection: digital input Short-circuit protection: output |
| Net weight | 0.5 kg |
