Schneider
VW3A7755 - Braking resistor - 8 ohms - 25 kW - IP23
| Kode Produk | VW3A7755 |
| Brand | Schneider |
| Kategori | Drives & Starters |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
This braking resistor is an option for variable speed drives of Altivar range. It has an Ohmic value of 8Ohms at 20°C. This braking resistor allows your variable speed drive to operate while braking to a standstill, by dissipating the braking energy and enables maximum transient braking torque. Its protection index is IP23. It weighs 86kg. This resistor is designed to be mounted on the outside of the enclosure, but should not inhibit natural cooling, air inlets and outlets must not be obstructed in any way.
Spesifikasi
| Range of product | Altivar |
|---|---|
| Range compatibility | Altivar Process ATV900 Altivar Machine ATV340 |
| Product or component type | Braking resistor |
| Ohmic value | 8 Ohm |
| [Ue] rated operational voltage | 24 V DC 250 V AC |
| Product compatibility | Variable speed drive ATV930 wall mount 55 kW 380...480 V severe cycle Variable speed drive ATV930 wall mount 15 kW 200...240 V severe cycle Variable speed drive ATV950 wall mount 55 kW 380...480 V severe cycle Variable speed drive ATV340 45 kW 380...480 V severe cycle Variable speed drive ATV930 75 kW 500...690 V severe cycle Variable speed drive ATV930 90 kW 500...690 V severe cycle Variable speed drive ATV930 100 hp 600 V severe cycle |
|---|---|
| Duty cycle | Severe cycle (heavy duty) <54 s braking with 100 % braking torque for a 120 s cycle Severe cycle (heavy duty) <6 s braking with 165 % braking torque for a 120 s cycle |
| Average power available | 25 kW at 50 °C |
| Electrical connection | terminal, connection capacity: <= 2.5 mm² / 12 AWG for temperature control switch M12 bar wire for drive |
| Protection type | Thermal protection via drive or temperature control switch at 120 °C |
| Width | 540 mm |
| Height | 1035 mm |
| Depth | 1060 mm |
| Net weight | 87.5 kg |
