Schneider
140ACI04000 - Analog input module Modicon Quantum - 16 I multirange
| Kode Produk | 140ACI04000 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Analog input module Modicon Quantum - 16 I multirange
Spesifikasi
| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | Analogue input module |
| Type of filter | Single pole low pass - 3 dB at 34 Hz +/- 25 % |
| Analogue input number | 16 |
|---|---|
| Input type | Differential |
| Addressing requirement | 17 input words |
| Analogue input resolution | 0...16000 counts 4...20 mA 0...20000 counts 0...20 mA 0...25000 counts 0...25 mA 0...4095 counts 4...20 mA |
| Absolute maximum input | 30 mA |
| Input impedance | 250 Ohm |
| Absolute accuracy error | +/- 0.125 % of full scale |
| Linearity error | +/- 12 µA max 4...20 mA +/- 6 µA max 0...20 mA +/- 6 µA max 0...25 mA +/- 6 µA max 4...20 mA |
| Accuracy drift according to temperature | +/- 0.0025 % of full scale/°C <= 0.0050 % of full scale /°C |
| Common mode rejection | > - 90 dB 60 Hz |
| Isolation between channels and bus | 1780 V AC for 60 s |
| Update time | 15 ms 2 wires/4 wires |
| Fault type | Broken wire 4...20 mA |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault 16 LEDs (green) for channel is turned on 16 LEDs (red) for channel fault |
| Bus current requirement | 360 mA |
| Power dissipation in W | 5 W |
| Module format | Standard |
| Net weight | 0.3 kg |
