Schneider
140CPS22400 - Power supply module Modicon Quantum - 24 V DC 20..30 V - redundant
| Kode Produk | 140CPS22400 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Power supply module Modicon Quantum - 24 V DC 20..30 V - redundant
Spesifikasi
| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | Power supply module |
| Power supply type | Redundant |
| Input voltage | 24 V (20...30 V) DC |
|---|---|
| Input current | 3800 mA |
| Inrush current | 14 A 20 V 25 A 24 V |
| Maximum input power interruption | 100 ms 1 ms 20 V |
| Associated fuse rating | 5 A, slow-blow |
| Output voltage | 5.1 V DC |
| Power supply output current | 8 A redundant |
| Output overvoltage protection | Internal |
| Output overload protection | 2.3 x maximum rated input voltage for 1.3 ms |
| Power dissipation | 6 + (1.8 x Iout) where Iout is in A |
| Alarm output | 1 NC 6 A 220 V power supply fault |
| Local signalling | 1 LED (green) for power (PWR OK) |
| Marking | CE |
| Module format | Standard |
| Net weight | 0.65 kg |
