Schneider
140CPU31110 - Unity processor, Modicon Quantum automation platform, Modbus Plus, 548kB RAM, 66MHz
| Kode Produk | 140CPU31110 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Unity processor, Modicon Quantum automation platform, Modbus Plus, 548kB RAM, 66MHz
Spesifikasi
| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | Unity processor |
| Clock frequency | 66 MHz |
|---|---|
| Number of slots | 16 4 10 2 6 |
| Number of racks | 2 - local rack(s) |
| Number of distributed I/O station | 63 station(s) - 1 rack(s) - 3 Modbus Plus network(s) |
| Number of remote I/O station | 31 - 2 rack(s) per S908 remote I/O 0 - 0 rack(s) per ethernet remote I/O |
| Discrete I/O number | Unlimited (27 slots max) - local 31744 inputs, 31744 outputs - remote 8000 inputs, 8000 outputs - distributed - per network Modbus Plus |
| Analogue I/O number | Unlimited (27 slots max) - local 500 inputs, 500 outputs - distributed - per network Modbus Plus 1984 inputs,1984 outputs - S908 remote I/O |
| Application specific I/O | High-speed interrupt inputs Counter Accurate time stamping Serial link |
| Number of optional modules | 2 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max) |
| Maximum number of connections | 1 USB 2 AS-Interface - distributed 2 Ethernet TCP/IP - local 2 Modbus Plus - local 2 Modbus (RS232/485 Modbus/ASCII) 2 Profibus DP - local 4 AS-Interface - remote |
| Integrated connection type | 1 Modbus Plus with 2 Modbus with |
| Checks | Process control |
| Memory description | Internal RAM 548 kB |
| Switch function | Slide switch communication port : ASCII/RTU/Memory Slide switch memory port/off |
| Application structure | 1 cyclic/periodic master task - 1 periodic fast task - 16 timer interrupt tasks - 64 I/O interrupt tasks - 64 interrupt tasks - No auxiliary task - |
| Execution time per instruction | 0.1...0.27 µs floating points 0.1...0.27 µs on fixed-point arithmetic 0.12...0.585 µs Boolean 0.12...0.585 µs on word |
| Number of instructions per ms | 1.86 Kinst/ms 100 % Boolean 2.49 Kinst/ms 65 % Boolean and 35 % numerical |
| System overhead | 0.2 ms for fast task 1 ms for master task |
| Bus current requirement | 1800 mA |
| Local signalling | 1 LED (green) for communications are active on the Modbus Plus port (Modbus Plus) 1 LED (green) for communications are active on the Modbus port (Modbus) 1 LED (green) for CPU has been started and is solving logic (RUN) 1 LED (green) for CPU has passed the power-up diagnostic tests (READY) 1 LED (orange) for write-protected memory (memory port) 1 LED (red) for battery needs replacing or is not present (BAT LOW) 1 LED (red) for communications error on the Modbus Plus port (ERROR A) |
| Electrical connection | 1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus network 2 female connectors, connector type: SUB-D 9 for connecting to the Modbus bus |
