Schneider
140DDI85300 - Discrete input module Modicon Quantum - 32 I - 10..60 V DC
| Kode Produk | 140DDI85300 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Discrete input module Modicon Quantum - 32 I - 10..60 V DC
Spesifikasi
| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | Dc discrete input modules |
| Discrete input number | 32 |
| Group of channels | 4 |
|---|---|
| Logic input | Positive (sink) |
| Input voltage limits | 10...60 V |
| Input voltage | 12 V 5…10 mA DC 24 V 6…30 mA DC 48 V 2…15 mA DC 60 V 1…5 mA DC |
| Voltage state 1 guaranteed | 9...12 V 12 V +/- 5 % 11...24 V 24 V - 15...20 % 34...48 V 48 V - 15...20 % 45...60 V 60 V - 15...20 % |
| Voltage state 0 guaranteed | 0...1.8 V 12 V +/- 5 % 0...10 V 48 V - 15...20 % 0...12.5 V 60 V - 15...20 % 0...5 V 24 V - 15...20 % |
| Absolute maximum voltage | 75 V |
| Addressing requirement | 2 input words |
| Response time | 4 ms from state 0 to state 1 4 ms from state 1 to state 0 |
| Switching frequency | <= 100 Hz |
| Isolation between group and bus | 2500 Vrms DC for 1 minute |
| Isolation between group | 700 Vrms DC for 1 minute |
| Power dissipation | 1 W + (0.25 x number of points on) |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) 32 LEDs (green) for input status |
| Bus current requirement | 300 mA |
| Module format | Standard |
| Net weight | 0.295 kg |
