Schneider
140DDO35301 - Discrete output module Modicon Quantum - 32 O - positive logic (source)
| Kode Produk | 140DDO35301 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Discrete output module Modicon Quantum - 32 O - positive logic (source)
Spesifikasi
| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | Dc discrete output module |
| Discrete output number | 32 |
| Group of channels | 4 groups of 8 |
|---|---|
| Discrete output logic | Positive logic (source) |
| Addressing requirement | 2 output words |
| Discrete output voltage | 24 V DC |
| Output voltage limits | 19.2...30 V |
| Absolute maximum output | 50 V for 1 s decaying pulse |
| Maximum voltage drop | <0.4 V 0.5 A |
| Maximum load current | 16 A per module 4 A per group |
| Surge current | 2 A |
| Response time | <= 0.1 ms at state 1 to state 0 <= 1 ms at state 0 to state 1 |
| Maximum leakage current | 1 mA 24 V |
| Load inductance | Inductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) |
| Fault indication | Loss of field power Blown fuse |
| Associated fuse rating | 3 A each point 5 A per group |
| Isolation between channels and bus | 1780 Vrms DC for 1 minute |
| Isolation between group | 500 Vrms DC for 1 minute |
| Protection type | Internal output protection by 5 A fuse per group |
| Power dissipation | 5 W |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 32 LEDs (green) for input status |
| Bus current requirement | 330 mA |
| Module format | Standard |
| Net weight | 0.45 kg |
