Schneider
BMXDDO1602 - Discrete output module M340 - 16 outputs - solid state - 24 V DC positive
| Kode Produk | BMXDDO1602 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
This discrete output module is part of the Modicon X80 modules. It has 16 transistor protected outputs, 24V DC. This module is connected via 20-way removable terminal block. It occupies a single slot on the rack and it has a case which provides IP 20 protection of the electronics.
Spesifikasi
| Range of product | Modicon X80 |
|---|---|
| Product or component type | Discrete output module |
| Discrete output logic | Positive |
| Response time on output | 1.2 ms |
|---|---|
| Maximum voltage drop | <1.2 V at state 1 |
| Insulation resistance | > 10 MOhm 500 V DC |
| Current per channel | 0.625 A |
| Maximum current per module | 10 A |
| Paralleling of outputs | Yes : 2 maximum |
| Switching frequency | 0.5/LI² Hz |
| Load impedance ohmic | > 48 Ohm |
| Reverse polarity protection | Reverse mounted diode |
| MTBF reliability | 410000 H |
| Protection type | External fuse reverse polarity protection short-circuit protection overload protection overvoltage protection |
| Voltage detection threshold | < 14 V DC preactuator fault > 18 V DC preactuator at state 0 |
| Net weight | 0.12 kg |
