Schneider
BMXXBP0800 - Rack M340 - 8 slots - panel, plate or DIN rail mounting
| Kode Produk | BMXXBP0800 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
This 8 slots rack is part of the Modicon X80 modules. Number of slots comprises processor, I/O, communication and application-specific modules (excluding power supply module). This rack can be mounted on DIN rail and its weight is 0.95kg.
Spesifikasi
| Range of product | Modicon X80 |
|---|---|
| Product or component type | Backplane |
| Number of slots | 8 bus X |
|---|---|
| Product compatibility | BMXP34 processor BMXCPS power supply I/O module Specific application module |
| Power consumption in W | 2.21 W |
| Electrical connection | 1 connector (XBE) expansion module |
| Fixing mode | By 4 M4/M5/M6 screws, mounting on panel By 4 M4/M5/M6 screws, mounting on mounting plate By clips, mounting on 35 mm symmetrical DIN rail |
| Height | 103.7 mm |
| Width | 372.8 mm |
| Depth | 19 mm |
| Net weight | 0.95 kg |
