Schneider
TSXDEY16D2 - Discrete input module, Modicon Premium, 16 inputs, compatible with 2/3 wires proximity sensors, 0.97W
| Kode Produk | TSXDEY16D2 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Discrete input module, Modicon Premium, 16 inputs, compatible with 2/3 wires proximity sensors, 0.97W
Spesifikasi
| Range of product | Modicon Premium Automation platform |
|---|---|
| Product or component type | Discrete input module |
| Discrete input number | 16 current sink isolated conforming to EN/IEC 61131-2 type 2 |
| Discrete input voltage | 24 V DC positive |
| Sensor power supply | 19…30 V |
| Input compatibility | With 2-wire/3-wire proximity sensors conforming to EN/IEC 60947-5-2 |
| Discrete input current | 7 mA |
| Voltage state 1 guaranteed | >= 11 V |
|---|---|
| Current state 1 guaranteed | >= 6.5 mA |
| Voltage state 0 guaranteed | <= 5 V |
| Current state 0 guaranteed | <= 2 mA |
| Input impedance | 4000 Ohm at state 1 |
| Response time | 4 ms <= 7 ms |
| isalotion resistance | < 10 MOhm 500 V DC |
| Power dissipation | (1 W + 0.15 W x No of channels used) |
| Electrical connection | Screw terminal |
| Marking | CE |
| Current consumption | 135 mA at 24 V DC 80 mA at 5 V DC |
| Module format | Standard |
| Net weight | 0.3 kg |
