Schneider
TSXP573623AM - Double format PL7 processor, Modicon Premium, Internal RAM 64Kwords program & data, transparent ready, PL7 Junior/Pro
| Kode Produk | TSXP573623AM |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Double format PL7 processor, Modicon Premium, Internal RAM 64Kwords program & data, transparent ready, PL7 Junior/Pro
Spesifikasi
| Range of product | Modicon Premium Automation platform |
|---|---|
| Product or component type | Double-format PL7 processor |
| Software designation | PL7 Junior/Pro |
| Concept | Transparent Ready |
|---|---|
| Number of racks | 16 4/6/8 slots 8 12 slots |
| Number of slots | 96 128 64 |
| Discrete I/O processor capacity | 1024 I/O |
| Analogue I/O processor capacity | 128 I/O |
| Number of application specific channel | 32 |
| Number of process control channel | 15 up to 45 simple loops |
| Integrated connection type | Ethernet TCP/IP RJ45 connector (10/100 Mbit/s) Non isolated serial link 2 female mini DIN connector (19.2/115 kbit/s) |
| Communication module processor capacity | 1 fieldbus modules (1 if CANopen used) 8 AS-Interface bus modules 2 fieldbus 2 network module |
| Memory description | Internal RAM (with PCMCIA card) 80 Kwords data Internal RAM (without PCMCIA card) 64 Kwords program and data PCMCIA card 2688 Kwords additional data storage PCMCIA card 384 Kwords program |
| Maximum size of object areas | 16384 %Mi located internal bits 30.5 %MWi internal words located internal data 32 %KWi constant words located internal data |
| Application structure | 1 master task 1 fast task 64 event tasks |
| Execution time per instruction | 2.6 µs floating points with PCMCIA card 0.12 µs Boolean without PCMCIA card 0.17 µs Boolean with PCMCIA card 0.17 µs word or fixed-point arithmetic without PCMCIA card 0.33 µs word or fixed-point arithmetic with PCMCIA card 2.5 µs floating points without PCMCIA card |
| Number of instructions per ms | 3.08 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card 4.49 Kinst/ms 100 % Boolean with PCMCIA card 4.7 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card 6.57 Kinst/ms 100 % Boolean without PCMCIA card |
| System overhead | 0.29 ms for fast task 1.15 ms for master task |
| Marking | CE |
| Local signalling | 1 LED (green) for Ethernet TCP/IP port ready (RUN) 1 LED (green) for processor running (RUN) 1 LED (red) for collision detection (COL) 1 LED (red) for Ethernet TCP/IP port fault (ERR) 1 LED (red) for I/O module or configuration fault (I/O) 1 LED (red) for processor or system fault (ERR) 1 LED (yellow) for activity on the terminal port (TER) 1 LED (yellow) for Ethernet link diagnostics (STS) 1 LED (yellow) for reception activity (RX) 1 LED (yellow) for transmission activity (TX) |
| Current consumption | 1360 mA at 5 V DC |
| Module format | Double |
| Net weight | 0.76 kg |
