Schneider
140ACO13000 - Analog output module Modicon Quantum - 8 O multirange
| Kode Produk | 140ACO13000 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Analog output module Modicon Quantum - 8 O multirange
Spesifikasi
| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | Analogue output module |
| Analogue output number | 8 |
|---|---|
| Addressing requirement | 8 output words |
| Loop voltage | 6…30 V DC |
| Maximum voltage drop | <30 V 25 mA |
| Analogue output range | 0...20 mA 0...20000 counts 0...25 mA 0...25000 counts 4...20 mA 0...16000 counts 4...20 mA 0...4095 counts |
| Absolute accuracy error | +/- 0.2 % of full scale at 25 °C |
| Linearity | +/- 12 µA 4...20 mA 0...4095 counts +/- 4 µA 0...20 mA 0...20000 counts +/- 4 µA 0...25 mA 0...25000 counts +/- 4 µA 4...20 mA 0...16000 counts |
| Accuracy drift according to temperature | 0.004 % of full scale/°C typical 0.007 % of full scale/°C maximum |
| Isolation between channels and bus | 1780 V for 1 minute AC |
| Update time | 5 ms |
| Setting time | 3.2 ms to +/-0.1% of the final value 1.6 ms to 5% of the final value |
| Fault type | Open circuit 4...20 mA |
| Bus current requirement | 550 mA |
| Maximum power dissipation in W | 5 W |
| External power requirement | 6...30 V |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault 8 LEDs (green) for channel is turned on 8 LEDs (red) for channel fault |
| Module format | Standard |
| Net weight | 0.3 kg |
