Schneider
140ATI03000 - Analog input module Modicon Quantum - 8 I thermocouple
| Kode Produk | 140ATI03000 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Analog input module Modicon Quantum - 8 I thermocouple
Spesifikasi
| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | Analogue input module |
| Type of filter | Notch filter - 3 dB at 50/60 Hz Single pole low pass - 3 dB at 20 Hz |
| Analogue input number | 8 |
|---|---|
| Addressing requirement | 10 input words |
| Analogue input type | Thermocouple: - 210...760 °C for thermocouple J Thermocouple: - 270...1000 °C for thermocouple E Thermocouple: - 270...1370 °C for thermocouple K Thermocouple: - 270...400 °C for thermocouple T Thermocouple: - 50...1665 °C for thermocouple R Thermocouple: - 50...1665 °C for thermocouple S |
| Analogue input resolution | 16 bits |
| Absolute accuracy error | +/- 2 °C plus + 0.1 % of reading thermocouple E +/- 2 °C plus + 0.1 % of reading thermocouple J +/- 2 °C plus + 0.1 % of reading thermocouple K +/- 2 °C plus + 0.1 % of reading thermocouple T +/- 4 °C plus + 0.1 % of reading thermocouple R +/- 4 °C plus + 0.1 % of reading thermocouple S |
| Linearity error | 1 °C, 0.1 °C, 1 F, 0.1 F - 210...760 °C 1 °C, 0.1 °C, 1 F, 0.1 F - 270...1000 °C 1 °C, 0.1 °C, 1 F, 0.1 F - 270...1370 °C 1 °C, 0.1 °C, 1 F, 0.1 F - 270...400 °C 1 °C, 0.1 °C, 1 F, 0.1 F - 50...1665 °C |
| Accuracy drift according to temperature | 0.15 µV/°C + 0.0015 % of reading/°C max low level voltage |
| Common mode rejection | > - 120 dB 50/60 Hz |
| Isolation between channels and bus | 1780 V AC for 60 s 2500 V DC for 60 s |
| Isolation between channels | 300 V DC 220 V AC |
| Update time | 1000 ms |
| Fault type | Broken wire Overtacking scale |
| Marking | CE |
| Cold junction compensation | Internal 0…60 °C |
| Local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault 8 LEDs (green) for channel is turned on 8 LEDs (red) for channel fault |
| Bus current requirement | 280 mA |
| Power dissipation in W | 1.5 W |
| Module format | Standard |
| Net weight | 0.3 kg |
