Schneider
140DAI54300 - Discrete input module Modicon Quantum - 16 I - 115 V AC - 2 channels
| Kode Produk | 140DAI54300 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Discrete input module Modicon Quantum - 16 I - 115 V AC - 2 channels
Spesifikasi
| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | VAC discrete input modules |
| Software name | Unity Pro Concept ProWORX 32 |
| Discrete input number | 16 |
| Group of channels | 2 |
|---|---|
| Addressing requirement | 1 input word |
| Discrete input voltage | 115 V AC |
| Input current | 11.1 mA at 57...63 Hz 13.2 mA at 47...53 Hz |
| Voltage state 1 guaranteed | 79...132 V AC at 57...63 Hz 85...132 V AC at 47...53 Hz |
| Voltage state 0 guaranteed | 0...20 V AC at 57...63 Hz 0...20 V AC at 47...53 Hz |
| Input impedance | 12000 Ohm capacitive at 57...63 Hz 14400 Ohm capacitive at 47...53 Hz |
| Network frequency limits | 47…63 Hz |
| Maximum leakage current | 2.1 mA |
| Absolute maximum input | 132 V continuous 156 V 10 s 200 V 1 cycle |
| Response time | 4.9...0.75 ms x line cycle Off-On 7.3...12.3 ms On-Off |
| Isolation between group | 1780 Vrms for 1 minute |
| Isolation between group and bus | 1780 Vrms for 1 minute |
| Bus current requirement | 180 mA |
| Maximum power dissipation in W | 5.5 W |
| Local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 16 LEDs (green) for input status |
| Marking | CE |
| Module format | Standard |
| Net weight | 0.3 kg |
