Schneider
140DAO84010 - Discrete output module Modicon Quantum - 16 O - 20..132 V AC
| Kode Produk | 140DAO84010 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Discrete output module Modicon Quantum - 16 O - 20..132 V AC
Spesifikasi
| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | AC discrete output modules |
| Discrete output number | 16 |
| Discrete output type | Isolated |
|---|---|
| Group of channels | 16 groups of 1 channel |
| Supply frequency | 47...63 Hz |
| maximum voltage drop | 1.5 V |
| Discrete output voltage | 20...132 V AC |
| Addressing requirement | 1 output word |
| Absolute maximum output | 156 V for 10 s AC 200 V during one cycle AC |
| Maximum load current | 1 mA rms 24 V off state leakage/points 1 mA rms 48 V off state leakage/points 2 mA rms 115 V off state leakage/points 16 A rms per module 4 A rms sum of four points, continuous 4 A rms 20...132 V each point |
| Surge current | 20 A during 2 cycles per point 30 A during 1 cycle per point 30 A during 3 cycles per point |
| DV/dt | 400 V/ms |
| Response time | <= 0.5 ms at state 0 to state 1 <= 0.5 ms at state 1 to state 0 |
| Protection type | Internal by RC filter |
| Power dissipation | 1.85 + (1.1 V x total module load current) |
| Associated fuse rating | 5 A |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 16 LEDs (green) for input status |
| Bus current requirement | 350 mA |
| Module format | Standard |
| Net weight | 0.485 kg |
