Schneider
140DDI35300 - Discrete input module Modicon Quantum - 32 I 24 V DC
| Kode Produk | 140DDI35300 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Discrete input module Modicon Quantum - 32 I 24 V DC
Spesifikasi
| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | Low voltage dc discrete input modules |
| Discrete input number | 32 |
| Group of channels | 4 |
|---|---|
| Logic input | Positive (sink) |
| Discrete input voltage | 24 V DC |
| Input voltage limits | 19.2...30 V |
| Voltage state 1 guaranteed | 15...30 V DC |
| Voltage state 0 guaranteed | -3...5 V DC |
| Current state 1 guaranteed | >= 2 mA at Us = 5.5 V and Uin = 0 V |
| Current state 0 guaranteed | <= 0.5 mA |
| Addressing requirement | 2 input words |
| Input impedance | 2500 Ohm |
| Maximum leakage current | 200 mA at Us = 5.5 V and Uin = 4 V |
| Absolute maximum input | 30 V continuous 56 V during 1.3 ms decaying pulse |
| Response time | <= 1 ms from state 0 to state 1 <= 1 ms from state 1 to state 0 |
| Protection type | Input protection by resistor limited |
| Power dissipation | 1.7 W + (0.36 x number of points on) |
| Isolation between group and bus | 1780 Vrms for 1 minute |
| Isolation between group | 500 Vrms for 1 minute |
| Local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 32 LEDs (green) for input status |
| Marking | CE |
| Bus current requirement | 330 mA |
| Module format | Standard |
| Net weight | 0.3 kg |
