Schneider
140DDI67300 - Discrete input module Modicon Quantum - 24 I - 125 V DC
| Kode Produk | 140DDI67300 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Discrete input module Modicon Quantum - 24 I - 125 V DC
Spesifikasi
| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | Dc discrete input modules |
| Discrete input number | 24 |
| Group of channels | 3 |
|---|---|
| Logic input | Positive (sink) |
| Input voltage limits | 88...150 V |
| Input voltage | 125 V 2.5 mA DC |
| Absolute maximum voltage | 156.25 V including ripple |
| Addressing requirement | 2 input words |
| Response time | 0.7 ms from state 0 to state 1 0.7 ms from state 1 to state 0 |
| Isolation between group and bus | 2500 Vrms DC for 1 minute |
| Isolation between group | 700 Vrms DC for 1 minute |
| Power dissipation | 1 W + (0.62 x number of points on) |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 24 LEDs (green) for input status |
| Bus current requirement | 200 mA |
| Module format | Standard |
| Net weight | 0.3 kg |
