Schneider
140DDO84300 - Discrete output module Modicon Quantum - 16 O - 10..60 V DC
| Kode Produk | 140DDO84300 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Discrete output module Modicon Quantum - 16 O - 10..60 V DC
Spesifikasi
| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | Dc discrete output module |
| Discrete output number | 16 |
| Group of channels | 2 groups of 8 |
|---|---|
| Discrete output logic | Positive logic (source) |
| Addressing requirement | 1 output word |
| Discrete output voltage | 10...60 V DC |
| Output voltage limits | 10.2...72 V |
| Absolute maximum output | 72 V permanent |
| Maximum voltage drop | <1 V 2 A |
| Maximum load current | 12 A per module 6 A per group |
| Surge current | 7.5 A for 50 s |
| Response time | <= 1 ms at state 0 to state 1 <= 1 ms at state 1 to state 0 |
| Maximum leakage current | 1 mA 60 V |
| Load inductance | Inductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) |
| Associated fuse rating | 2 A each point 8 A per group |
| Isolation between channels and bus | 2500 Vrms DC for 1 minute |
| Isolation between group | 700 Vrms DC for 1 minute |
| Protection type | Internal output protection by 8 A fuse per group |
| Power dissipation | 1 W + (1 V x total module load current) |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 16 LEDs (green) for input status |
| Bus current requirement | 160 mA |
| Module format | Standard |
| Net weight | 0.45 kg |
