Schneider
140DRA84000 - Discrete output module Modicon Quantum - 16 O
| Kode Produk | 140DRA84000 |
| Brand | Schneider |
| Kategori | PLC & I/O Module |
Pengiriman ke seluruh Indonesia via ekspedisi terpercaya
Deskripsi
Discrete output module Modicon Quantum - 16 O
Spesifikasi
| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | Relay discrete output module |
| Discrete output number | 16 |
| Contacts type and composition | 1 NO |
|---|---|
| Contact form | Form A |
| Discrete output voltage | 20...250 V AC 30...150 V DC 5...30 V DC |
| Addressing requirement | 1 output word |
| Minimum load | 50 mA at 20...250 V AC 50 mA at 5...30 V DC |
| Maximum load current | 1 A 250/30 V AC/DC 1/8 hp cos phi = 0.4 1 A 250/30 V AC/DC tungsten 2 A 250/30 V AC/DC resistive at 60 °C 300 mA 30...50 V DC resistive |
| Surge current | 10 A for 10 ms capacitive |
| Switching capacity in VA | 500 VA resistive |
| Maximum response time on input open | 10 ms at state 0 to state 1 20 ms at state 1 to state 0 |
| Mechanical durability | 10000000 cycles |
| Electrical durability | 100000 cycles 100 mA 30...150 V DC L/R = 10 ms 100000 cycles 2 A 30 V DC resistive 100000 cycles 30...150 V DC interposing relay 100000 cycles 300 mA 30...150 V DC resistive 200000 cycles 2 A 250 V AC resistive 50000 cycles 500 mA 30...150 V DC resistive |
| Output overvoltage protection | Internal by varistor, 275 V |
| Isolation between channels | 1780 Vrms AC for 1 minute |
| Isolation between channels and bus | 1780 Vrms AC for 1 minute 2500 V DC for 1 minute |
| Power dissipation | 5.5 W + (0.5 x the number of points on) |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 16 LEDs (green) for input status |
| Bus current requirement | 1100 mA |
| Module format | Standard |
| Net weight | 0.41 kg |
